| Fuel type : |
Pellet (Premium grade or better) (2) |
| Recommended heating area-ft² : (*) |
500 - 2,200 |
| Hopper capacity : |
55 lb (25 kg) |
| Maximum burn time : (*) |
45 h |
| Maximum heat input rate : (3) |
43,000 BTU/h (12.6 kW) |
| Overall heat output rate < : (4) |
6,400 BTU/h (1.9 kW) to 29,300 BTU/h (8.6 kW) |
| Average overall efficiency : (5) |
69.8% (HHV) (6) |
75.3% (LHV) (7) |
| Optimum efficiency : (8) (9) |
77.2% |
| Burn rate : |
1.2 lb/h - 5.0 lb/h |
| Average particulate emissions rate : (10) |
2.9 g/h |
| Average CO : (11) |
41.2 g/h |
| Average electrical power consumption for ignition cycle : (12) |
3.1A (372W) |
| Average electrical power consumption for continuous operation : (12) |
2.3A (90W) - 3.1A (174W) |
(1) Values are as measured per CSA B415.1-10, except for the recommended heating area, hopper capacity, maximum burn time and maximum heat input rate. Results may vary depending on pellet quality, density, length, and diameter.
(2) Grades of pellet fuel are determined by organizations such as Pellet Fuels Institute (PFI), ENplus and CANplus.
(*) Recommended heating area and maximum burn time may vary subject to location in home, chimney draft, heat loss factors, climate, fuel type, feed rate, fuel level, and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature considering that the space configuration and the presence of heat distribution systems have a significant impact in making heat circulation optimum.
(3) Based on the maximum burn-rate and a dry energy value of pellet at 8,600 BTU/lb.
(4) As measured per CSA B415.1-10 stack loss method.
(5) Efficiency based on radiated and delivered heat when allowing cycling from high to low burn to simulate thermostat demand.
(6) Higher Heating Value of the fuel.
(7) Lower Heating Value of the fuel.
(8) Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.
(9) Optimum overall efficiency at a specific burn rate (LHV).
(10) This appliance is officially tested and certified by an independent agency.
(11) Carbon monoxyde.
(12) Unless stated otherwise, measures were taken directly at the main power source and include all electrical components present in the appliance.
General Features
| Combustion technology |
Bottom-feed |
| High-efficiency certified appliance |
CSA B415.1-10 |
| Electronic igniter |
Yes |
| Flue outlet diameter |
3" |
| Type of chimney |
ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L) |
| Baffle type |
Stainless steel |
| Approved for an alcove installation |
Yes |
| Approved for a mobile home installation |
Yes, with fresh air intake |
| Shipping Weight |
367 lb (167 kg) |
| Door type |
Single, glass with cast iron frame |
| Glass type |
Ceramic glass |
| Glass surface – dimensions (Width X Height) |
13 3/8" X 7 3/4" |
| Glass air-wash system |
Yes |
| Premium quality blower included (CFM) |
176 |
| Noise level at 6 feet |
47 dBa (+/- 3 dBa) - 59 dBa (+/- 3 dBa) |
| Overall dimension (Height) |
32 5/8" |
| Overall dimension (Width) |
24 3/8" |
| Overall dimension (Depth) |
30 5/8" |
| Adjustable threaded legs |
No |
| Easy-to-access ash drawer |
N.A. |
| Voltage and frequency |
120 VAC - 60 Hz |
| AC Current |
2.3A/120 VAC - 3.1A/120 VAC |
| Main control board fuses |
7.5A - 250V |
| Canadian Standard (emissions) |
CSA B415.1-10 |
| USA standard (safety) |
UL 1482, ASTM E1509 |
| Canadian standard (safety) |
ULC S627 |
| Tested and listed as per applicable standards |
By an accredited laboratory (CAN/USA) |
| Warranty |
Limited lifetime |
Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm) |
| |
Canada |
United-States |
| Clearance – back wall |
3" |
3" |
| Clearance - corner |
3" |
3" |
| Clearance – side wall |
6" |
6" |
| Clearance – top (measured from the platform on which the appliance is installed)** |
48" |
48" |
|
* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).
|
|
** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
|
Specifications
|
BTU
|
43,000
|
|
Heating Capacity
|
500-2,200 sq ft
|
|
Loading Capacity
|
55 lbs
|
|
Maximum Combustion Time
|
45 hrs |
|
Flue Pipe Diameter
|
3”
|
|
Weight
|
386 lbs
|
|
Width
|
24 3/8”
|
|
Depth
|
30 5/8”
|
|
Height
|
32 5/8” |
|
Mobile Home Approved
|
Yes |
Options
|
2" X 25' Anti-Static Flex Hose
|
 |
|
3" X 10' Insulated Flex Pipe for Fresh Air Intake Kit
|
 |
|
3" X 5' Fresh Air Intake Kit
|
 |
|
Digital Wall Thermostat
--- always displays ambient temperature
|
 |
|
Glass Hearth Pad 10mm - 44" X 36"
--- Offers a contemporary alternative to traditional hearth boards
|
 |
|
Leg Assembly for AC01463 Discharge Tank
--- Allows for floor-based installation
|
 |
|
Programmable Thermostatic Remote Control
|
 |
|
Stand Alone Auxiliary Discharge Tank
--- unit contains all the necessary elements to be hung on the wall
|
 |
|
Storage Tank Extension for AC01460
--- Gives the equivalent to one ton of pellets in total
|
 |
|
Storage Tank with Pneumatic Self-Feeding Pellet System
--- Allows long heating autonomy for pellet appliances
|
 |
Accessories
|
Adhesives, Gaskets and Insulation
|
High Temperature Red Silicone (300 ml - 10.1 fl.oz.)
|
 |
|
High Temperature Clear Silicone (300 ml - 10.1 fl.oz.)
|
 |
|
|
Paint
|
Metallic Black Stove Paint – 342g (12oz) Aerosol
|
 |
|
Metallic Black Stove Paint – 85g (3oz) Aerosol
|
 |
|
|
Maintenance Products
|
Stove and Furnace Cement (300ml - 10.1fl.oz.)
--- helps prevent smoke and air leaks
|
 |
|
Ash Vacuum Cleaner
--- designed almost exclusively for ash collection
|
 |
|
3'' Pellet Stove Cleaning Kit
|
 |
|
5' Pellet Stove Flexible Rod (1/4"-20 Thread)
|
 |
|
Dry Cleaning Pad
--- easily cleans the soot from glass without water
|
 |
|
Pellet Appliance Glass Cleaner (500 ml - 16.9 fl.oz.)
|
 |
|
|
Hearth Pads
|
Modular Floor Protection System
--- easy to assemble modular panel construction and simple clip together design requires no fasteners
|
 |
|
|
Heat Shields
|
Certified Modular Heat Shield System Extension
--- reduces clearances by up to 87.5% which includes mounting support brackets and hardware
|
 |
|
53" X 58 1/2" Certified Modular Heat Shield System
|
 |
|
