SKU
VB00012-B
Ventis HEI240 Wood Insert with Blower
From $2,095.00
To $3,175.00
VENTIS HEI240 Wood Insert with Blower
Features
- Size: 28 Inches
- Color: Black
- Product Dimensions: 28 1/2" W x 22 7/8" H x 26 3/4" D
- Non-catalytic
- EPA certified
- Cast iron door
- Large wood insert
- EPA 2020 approved
- 144 CFM quiet blower
- Glass air-wash system
- High quality vermiculite baffle
- Solidity and manufacturing quality
- Stainless-steel secondary-air system
Technical Specifications
- Maximum BTU Output with Dry Cordwood: 75,000 BTU
- Average Overall Efficiency: 69%
- Average Particulate Emissions Rate: 1.54 g/h
- Recommended Heating Area: 500 - 2,100 sq. ft.
- Firebox Dimensions: 21" W x 11 7/8" H x 14 1/4" D
- Minimum Fireplace Size Requirements: 28 1/2" W x 23 1/2" H x 15 15/16" D
- Glass Viewing Area: 16 7/8" W x 10 1/4" H
- Recommended Log Size: 18"
- Maximum Log Size: 20"
Additonal Features:
-
2.4 cu. ft. firebox
-
Heating capacity 850 to 2,100 sq. ft.
-
Optimum efficiency : 77%
-
Emissions: 1.54 g/h
-
BTU/hr, seasoned cord wood: 75,000
-
Maximum log length: 20''
-
Flue diameter: 6''
-
Minimum fireplace opening: 23-3/8''H x 28-7/8''W x 15-3/4''D Air-wash system
-
Fire viewing area: 173 sq. inches
-
Tested by Intertek as per applicable standards (CSA/UL/ULC and/or others)
-
Adapter for exterior air intake
-
Washington State Approved
-
Vermiculite baffle
-
Non-catalytic
-
Large appliance
-
Premium manufacturing quality
-
Non-catalytic combustion technology
-
Cast iron door
